100m Deep Electric Folded Water Well Drilling Rig Machine

100m deep Electric folded water well drilling rig machine
 Folding Hydraulic Drilling Machine is an efficient, portable, economical and practical new mechanized drilling machine produced by our factory. Its advantages are: large torque, small volume, portable, high efficiency, easy operation, low noise, and adaptability to various environmental topography. The machine is easy to use, simple to operate, fast to form holes. It can be operated by a single person at about 10 meters per hour. It can dump the drill pipe mechanically. Taking a well drilled at 100 meters as an example, the average time of drill pipe disassembly takes about 10 minutes. After completion of drilling operation, the machine can be moved by a single person.
,,,,,,,,,.
Hydraulic oil Pump, parallel transmission design, separate single oil pump, reasonable power distribution, unique design of hydraulic system, power head gearbox, dual motor power supply, large torque, durable, simple maintenance and low cost.

Parameter	Unit	BF-folding hydraulic drilling rig
Power Source		Motor or Diesel Engine
Hydraulic oil		46#
Hydraulic Motor	Kw	110
Borehole diameter	mm	32-220
Drill pipe diameter		1 inch, 1.2 inch, 1.5 inch various specifications and lengths can be selected
Bit Specification		Multi-bore Alloy and Diamond Bit Selection
Drilling depth	M	100
weight	Kg	715
Suitable for soil		mud layer, quicksand layer, small amount of rock layer, pebble, etc.

Contact us if you need more details on Water Well Drilling Rig. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Water Well Drilling Machine、Drilling Rig. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Drilling Machinery
